JH6000D-4 Comprehensive detector

recommendation index：

Detection components, high accuracy, good stability

Portable design, fast testing, low air consumption, environmentally friendly

Automatic flow control, efficient and accurate, effectively reducing sample gas emissions

Automatic judgment of detection endpoints, suitable for different places

Detect the main products of cracking of insulating materials inside SF6 electrical equipment: SO₂, SOF₂, H₂S, CO, HF, H₂ content (H₂ is optional)

name	component	parameter
minimum detectable quantity	SO₂+SOF₂、H₂S、HF	≤0.1μL/L
	CO/H₂	≤0.5μL/L
	purity	≤0.03%（V/V)
	Dew point: resistance capacitance	≤0.1℃
precision	SO₂+SOF₂、H₂S、HF	measurement value≤ 10 μL/L, error ≤ ± 0.5 μL/L measured value > 10 μL/L, error ≤ ± 5%.
	CO/H₂	measurement value ≤ 50 μL/L, error ≤ ± 2.0 μL/L measurement value > 50 μL/L, error ≤ ± 4%
	purity	≤±0.1 %(W/W)
	resistance capacitance/mirror	≤±1℃/±0.3℃
repeatability	SO₂+SOF₂ 、H₂S、HF	measured value ≤ 10 μL/L, ≤ 0.2 μL/L 10μL/L～100μL/L:2%.
	CO/H₂	measured value is ≤ 50 μL/L, ≤ 1.5 μL/L detection value ：50 μL/L ~1000 μL/L: ≤ 3%
	purity	≤0.05%(W/W)
	resistance capacitance/mirror	＜1%（RSD）
range	SO₂+SOF₂	0～100μL/L,0～2000μL/L
	H₂S	0～100μL/L
	HF	0～20μL/L
	CO/H₂	0～1000μL/L
	purity	0～100%
	resistance capacitance/mirror	-80℃～+20℃/-60℃～+20℃@30℃
